Mixer

MMICS

PN

Description

Freq LO/RF

(GHz)

Freq IF

(GHz)

Lo Drive

(dBm)

Conver

Gain

(dB)

LO-RF

Isolation

(dB)

LO-IF

Isolation

(dB)

Input P1dB

(dBm)

Package

SAC3507

Double Balanced

0.9~3.0

DC~0.8

0

-7

-40

-30

-

Die or QFN

SAC3501

Up-Converter

2.0~3.5

0.01~ 0.6

0

8

-40

-60

-

Die or QFN

SAC3502

Down-Converter

2.0~3.5

0.01~ 0.6

0

13

-45

-47

-

Die or QFN

SAC3503

Down-Converter

2.0~3.5

0.01~ 0.6

0

13

-45

-47

-

Die or QFN

SAC3508

Double Balanced

2.0~6.0

DC~2

0

-7

-25

-20

-

Die or QFN

SAC3505

Double Balanced

3.5~9

DC~ 1

+13

-7

-35

-21

12

Die or QFN

SAC3509

Double Balanced

5.0~10

DC~4

0

-8

-38

-35

-

Die or QFN

SAC3504

Double Balanced

7.0~14

DC~3

+13

-5

-35

-27

-6

Die or QFN

SAC3506

Double Balanced

11~20

DC~4

+13

-5

-30

-27

10

Die or QFN

Part number

Footprint

Type

RF BW [GHz]

IF BW [GHz]

CL [dB]

IRR [dB]

LO-RF

isolation [dB]

LO power

[dBm]

gMQR0011

dxf

IQ demod

70-95

0-10

10

>24

-

5

gMDR0015

dxf

IQ mod

71-86

0-10

10

>25

>30

7

gMDR0026

-

IQ mod

57-66

0-12

9

>25

>30

7

gMBR0011

dxf

Balanced

mixer

70-100

0-10

10

-

>27

7
