Microstrip Ferrite Circulator

Passive Components > ferrite

Single Junction Circulator
Model No.	Freq.Range	BW	IL.	Isolation	VSWR	Forward	Reverse	Connector	Temp.	Dimension
Model No.	(GHz)	Max.	(dB)	(dB)	VSWR	Power(W)	Power(W)	Type	(°C)	LxWxH(mm)
UIYMC1414A	2.7~4.9	40%	0.4	20	1.2	15	15	Microstrip	-55~+85	14×14×5.5
UIYMC1212A	4.0~5.85	30%	0.4	20	1.2	15	15	Microstrip	-55~+85	12×12×4
UIYMC1010A	5.0~7.5	20%	0.4	20	1.2	15	15	Microstrip	-55~+85	10×10×4
UIYMC77A	7.0~9.5	25%	0.5	20	1.25	15	15	Microstrip	-55~+85	7×7×3.5
UIYBMC66A	8.0~12.0	Full	0.6	16	1.35	10	10	Microstrip	-55~+85	6×6×2.5
UIYMC66A	8.0~18.0	40%	0.5	20	1.25	10	10	Microstrip	-55~+85	6×6×2.5
UIYBMC66B	11.0~18.0	Full	1.0	15	1.45	10	10	Microstrip	-55~+85	6×6×3
UIYMC94A	12.0~13.5	Full	0.5	20	1.25	15	15	Microstrip	-40~+85	9×4×3
UIYMC55B	15.0~27.5	20%	0.5	20	1.25	10	10	Microstrip	-55~+85	5×5×3.5
UIYMC55A	24.0~31.0	12%	0.7	15	1.4	5	5	Microstrip	-55~+85	5×5×3.2

Dual Junction Circulator
Model No.	Freq.Range	BW	IL.	Isolation	VSWR	Forward	Reverse	Connector	Temp.	Dimension
Model No.	(GHz)	Max.	(dB)	(dB)	VSWR	Power(W)	Power(W)	Type	(°C)	LxWxH(mm)
UIYDMC108A	8.0~12.0	20%	0.5	30	1.25	10	5	Microstrip	-55~+85	10×8×2.5
UIYDMC108B	8.0~12.0	20%	0.5	30	1.25	10	5	Microstrip	-55~+85	10×8×2.5
UIYDMC87A	14.0~18.0	25%	0.45	30	1.25	10	3	Microstrip	-55~+85	8×7×2.5
UIYDMC87B	14.0~18.0	25%	0.45	30	1.25	10	3	Microstrip	-55~+85	8×7×2.5

Dual Junction Circulator – Magnetic Shield
Model No.	Freq.Range	BW	IL.	Isolation	VSWR	Forward	Reverse	Connector	Temp.	Dimension
Model No.	(GHz)	Max.	(dB)	(dB)	VSWR	Power(W)	Power(W)	Type	(°C)	LxWxH(mm)
UIYDMC109A	8.0~12.0	20%	0.45	30	1.25	10	5	Microstrip	-55~+85	10.4×9×4
UIYDMC109B	8.0~12.0	20%	0.45	30	1.25	10	5	Microstrip	-55~+85	10.4×9×4
UIYDMC87C	14.0~18.0	25%	0.45	30	1.25	10	3	Microstrip	-55~+85	8×7×4
UIYDMC87D	14.0~18.0	25%	0.45	30	1.25	10	3	Microstrip	-55~+85	8×7×4
