Switches

MMICS

P/N

Description

Freq

GHz)

Insertion

Loss

(dB)

Isolation

(dB)

Intput

P-1dB

(dBm)

Return

Loss

(db)

Switch

Speed

(nsec)

Control

Voltage

(V)

Package

SAC3207

SPST

DC12

0.9

-40

27

-20

5

0/-5V

Die or QFN

SAC3208

SPST

DC12

0.8

-50

N/A

-15

N/A

0/+5V

Die or QFN

SAC3209

SPST

DC20

2.0

-50

N/A

-15

N/A

0/+5V

Die or QFN





















SAC3204

SPDT

DC~4

1.2

-70

30

-15

70

0/+5 V

Die or QFN

SAC3210

SPDT

0.56

1.1

-40

30

-20

15

0/±5V

Die or QFN

SAC3211

SPDT

0.5 ~ 6

1.0

-45

N/A

-20

17

0/±5V

Die or QFN

SAC3202

SPDT

DC~12

1.2

-48

25

-20

18

0/+5 V

Die or QFN

SAC3203

SPDT

DC~12

1.2

-48

25

-20

18

0/+5 V

Die or QFN

SAC3216

SPDT

DC12

1.2

-45

30

-15

15

0/-5V

Die or QFN

SAC3212

SPDT

1.5 ~ 12

1.5

-35

30

-15

15

0/±5V

Die or QFN

SAC3201

SPDT

DC20

2.3

-45

30

-15

15

0/-5V

Die or QFN

SAC3205

SPDT

DC20

1.5

-40

20

-18

17

0/+5V

Die or QFN

SAC3206

SPDT

DC20

2.3

-45

30

-15

15

0/+5V

Die or QFN





















SAC3213

SP3T

0.5 ~ 3.5

1.0

-50

N/A

-20

30

0/+5V

Die or QFN

SAC3214

SP3T

DC ~ 8

1.5

-45

25

-20

30

0/+5V

Die or QFN

SAC3215

SP3T

DC ~ 8

1.5

-45

25

-20

30

0/+5 V

Die or QFN











Part number

Footprint

Type

Freq [GHz]

loss [dB]

Isolation [dB]

RL on/off [dB]

gSSS0013

dxf

SPST

40-110

<2.5

>26

12/10

gSSS0015

dxf

SPST

40-110

<2.5

>26

12/10

gSSD0011

-

SPDT

40-110

<2.5

>26

12/10
