SMD Fixed Attenuator
Passive Components
|
Part No. |
Frequency |
Power Rating |
VSWR |
Dimensions(mm) |
|||||
|
|
(GHz) |
（W） |
(Max) |
W |
L |
T |
H |
I |
B |
|
MYXCA10-XX-3N01 |
DC-3 |
10 |
1.20 |
6.35 |
6.35 |
|
1 |
1 |
1 |
|
MYXCA30-XX-3N01 |
DC-3 |
30 |
1.20 |
9.50 |
9.50 |
|
1 |
1 |
1 |
|
MYXCA10-XX-3B01 |
DC-3 |
10 |
1.20 |
4 |
4 |
1 |
2.2 |
1 |
1 |
|
MYXCA30-XX-3B01 |
DC-3 |
30 |
1.20 |
6 |
6 |
1 |
2.2 |
1 |
1 |
|
MYXCA100-XX-3B01 |
DC-3 |
100 |
1.20 |
9 |
6 |
1 |
2.2 |
1 |
1 |
|
MYXCA100-XX-3B02 |
DC-3 |
100 |
1.30 |
9.5 |
6.35 |
1 |
2.2 |
1 |
1 |
|
MYXCA100-XX-3B03 |
DC-3 |
100 |
1.30 |
10 |
10 |
1 |
2.2 |
1 |
1.4 |
|
MYXCA250-XX-1B01 |
DC-1 |
250 |
1.25 |
12.7 |
12.7 |
1.5 |
2.2 |
2 |
2.4 |
|
MYXCA5-XX-6B01 |
DC-6 |
5 |
1.20 |
2.5 |
5 |
1 |
2.2 |
1 |
1 |
|
MYXCA10-XX-3B02 |
DC-3 |
10 |
1.20 |
2.5 |
5 |
1 |
2.2 |
1 |
1 |
|
MYXCA10-XX-3B03 |
DC-3 |
10 |
1.20 |
4 |
4 |
1 |
2.2 |
1 |
1 |
|
MYXCA30-XX-3B02 |
DC-3 |
30 |
1.20 |
6 |
6 |
1 |
2.2 |
1 |
1 |
|
*Remark: |
|||||||||
|
1)Tolerance
of dimension: +/-2% |
|||||||||
|
2) XX-attenuation
value |
|||||||||
|
3) Material: BeO and ALN are both available |
|||||||||
