Multi-port RF Connection
Multi-port series include 4 ports, 5 ports, 8 ports and 11 ports products. And customization is also available.
Multi-Port series are special designed for applications having limited space but need compositive function, customers who have performance demands and sensitive with cost, designers who required greater flexibility on configurations while contain system robustness.
We offers the following 4 types as they’re frequently applied.
 |  |  |
|
MP11R |
MP4C |
MP8C(38999) |
MP5R |
|
|
Ports |
11 |
4 |
8 |
5 |
|
Frequency |
DC~6GHz |
DC~6GHz |
DC~6GHz |
DC~6GHz |
|
VSWR |
1.25 |
1.2 |
1.25 |
1.2 |
|
Shielding eff |
>90dB |
>90dB |
>90dB |
>90dB |
|
Impedance Ω |
50 |
50 |
50 |
50 |
|
IL dB/m |
1.6 |
2.0 |
0.96 |
0.8 |
|
Typical application |
1. Darkroom test cabinet module |
1. 5G testing
platform |
1. avionics
system |
1. Ground satellite test platform |
|
2. Microwave antenna system |
2. 5G system interconnection |
2. Multi-channel
test platform |
2. avionics
communication system |
