Ultra-Wideband Optical Modulation Amplifier
The MXOA series Ultra-Wideband Optical Modulation Amplifier covers a frequency range from 50 kHz to 67 GHz.
It utilizes thin-film hybrid integration technology, offering broad bandwidth, low noise and excellent consistency.
The MXOA amplifiers combine compact size, lightweight design, affordability and short delivery cycles, while maintaining high performance.
They are suitable for demanding applications such as radar systems, electronic warfare and high-speed communication systems.
Key Features
- Compact Thin-Film Hybrid Design: low noise, stable and repeatable performance
- Small Size & Lightweight: easy integration in demanding systems
- Cost-Effective Solution: strong performance at an optimized price
- Fast Delivery: short lead times for urgent projects
- Proven Applications: radar, electronic warfare, and communication systems (ground, airborne, shipborne)
| Model | Min Freq | Max Freq | Gain (dB) | P1 (dBm) | NF (dB) | Gain Flatness (±dB) | VSWR | Voltage | Connector |
|---|---|---|---|---|---|---|---|---|---|
| MXOA-000200G30-01 | 50 kHz | 20 GHz | 30 | 20 | 5.0 | ±2.0 | 2.0 | 9 V | 2.92 mm |
| MXOA-000200G30-02 | 50 kHz | 20 GHz | 30 | 22 | 3.5 | ±2.0 | 1.8 | 12 V | SMA |
| MXOA-000430G27-01 | 50 kHz | 43 GHz | 27 | 20 | 6.0 | ±2.5 | 2.0 | 8 V | 2.92 mm |
| MXOA-000670G18-01 | 50 kHz | 67 GHz | 18 | 15 | 6.0 | ±2.5 | 2.0 | 8 V | 1.85 mm |
| MXOA-000670G20-02 | 50 kHz | 67 GHz | 20 | 13 | 5.0 | ±2.0 | 1.8 | 12 V | 1.85 mm |
