Schottky zero bias diodes

Microelectronics Components > ACTIVE > Diodes

Schottky zero bias diodes

Vbr to be used as primary sort.



Part Number

Vbr(min)

If(min)

Ct0(max) @ 0V

Rv(typ) @

Sensitivity (typ)

Recommended

RFQ

&

Quote

Ir= 100mA

Vf= 1V

f= 1 MHz

If= 2mA/4mA

Upper Freq

(volts)

(mA)

(pF)

(ohms)

( mV/ mW)

Limit

MP2051

1

3

0.1

3000

8000

26

RFQ

MP2052

1

3

0.27

3000

8000

18

RFQ

MP2053

1

3

0.1

3000

8000

40

RFQ

MP2054

1

3

0.32

3000

8000

12

RFQ

MP2055

1

3

0.28

3000

8000

18

RFQ

MP2056

1

3

0.15

3000

8000

18

RFQ

MP2057

1

3

0.27

3000

8000

18

RFQ

MP2061

2

4

0.1

5000

10000

26

RFQ

MP2062

2

4

0.27

5000

10000

18

RFQ

MP2063

2

4

0.1

5000

10000

40

RFQ

MP2064

2

4

0.32

5000

10000

12

RFQ

MP2065

2

4

0.28

5000

10000

18

RFQ

MP2066

2

4

0.15

5000

10000

18

RFQ

MP2067

2

4

0.27

5000

10000

18

RFQ

MP2071

3

5

0.1

8000

12000

26

RFQ

MP2072

3

5

0.27

8000

12000

18

RFQ

MP2073

3

5

0.1

8000

12000

40

RFQ

MP2074

3

5

0.32

8000

12000

12

RFQ

MP2075

3

5

0.28

8000

12000

18

RFQ

MP2076

3

5

0.15

8000

12000

18

RFQ

MP2077

3

5

0.27

8000

12000

18

RFQ



EVIRONMENTAL RATING
-----------------(MAXIMUM)---------------
Operating Temperature ...................-65°C to +150°C
Storage Temperature.......................-65°C to +200°C

Power Dissipation @ 25°C..............100mW. Derate
...............................................Linearly to zero at 150°C
Soldering Temperature...........230°C for 5 seconds
