PIN Diodes BEAM LEAD & SMT for Hi frequency Switching

Microelectronics Components > ACTIVE > Diodes

BEAM LEAD (B1) & SURFACE MOUNT (M2)

Heatsink is anode

Part Number

Vbr(min)

Cj(max) @ 10V

Rs(typ)

tL(typ)

Application

RFQ

Ir = 10mA

f = 1 MHz

If = 10mA

If = 10/6mA

(volts)

(pF)

( W )

(nS)

Beam Lead

MP5220

70

0.02

6

30

Switching Diode

RFQ

Beam Lead

MP5221

70

0.025

5

50

Switching Diode

RFQ

Beam Lead

MP5222

70

0.035

4

60

Switching Diode

RFQ

Surface Mount

MP5230

70

0.045

6

30

Switching Diode

RFQ

Surface Mount

MP5232

70

0.055

4

60

Switching Diode

RFQ

NIP Diode

MP5401

70

0.08

2

35

Fast Switch Diode

RFQ

NIP Diode

MP5402

70

0.08

2

35

Fast Switch Diode

RFQ

NIP Diode

MP5403

70

0.08

2

35

Fast Switch Diode

RFQ

NIP Diode

MP5404

70

0.08

2

35

Fast Switch Diode

RFQ

NIP Diode

MP5405

70

0.08

2

35

Fast Switch Diode

RFQ

NIP Diode

MP5411

100

0.12

2

100

Switching Diode

RFQ

NIP Diode

MP5412

100

0.12

2

100

Switching Diode

RFQ

NIP Diode

MP5413

100

0.12

2

100

Switching Diode

RFQ

NIP Diode

MP5414

100

0.12

2

100

Switching Diode

RFQ

NIP Diode

MP5415

100

0.12

2

100

Switching Diode

RFQ

NIP Diode

MP5441

200

0.12

2

200

Switching Diode

RFQ

NIP Diode

MP5442

200

0.12

2

200

Switching Diode

RFQ

NIP Diode

MP5443

200

0.12

2

200

Switching Diode

RFQ

NIP Diode

MP5444

200

0.12

2

200

Switching Diode

RFQ

NIP Diode

MP5445

200

0.12

2

200

Switching Diode

RFQ

NIP Diode

MP5448

200

0.25

3

200

High Power Diode

RFQ

NIP Diode

MP5449

200

0.25

3

200

High Power Diode

RFQ

NIP Diode

MP5450

200

0.25

3

200

High Power Diode

RFQ

NIP Diode

MP5451

200

0.25

3

200

High Power Diode

RFQ

NIP Diode

MP5452

200

0.25

3

200

High Power Diode

RFQ



EVIRONMENTAL RATING
-----------------(MAXIMUM)---------------
Operating Temperature ...................-65°C to +150°C
Storage Temperature........................-65°C to +200°C
