High Power Tunable Filters

PART Number

Frequency Tuning

Range

(MHz)

3 dB BW

(MHz)

40 dB BW

(MHz)

I.L (dB)

Frequency Tuning

Frequency

Tuning Step

(MHz)

Max. Input Power (CW, W)

Operating

Temperature

°C

Dimensions

(L*W*H)

(mm)

Package

ADTBF 1025-1150A

1,025 ~ 1,150

8.2 ± 1.6

55

1.0

RS232C

1

100

-40 ~ +85

130*110*76

SMA

PART Number

Frequency Tuning Range

(MHz)

3 dB % BW

(%)

Shape Factor

(30dB/3dB)

or selectivity @10%

I.L

(dB)

Tuning Control

In-band Handling Power

(CW, W)

Operating temperature °C

Dimensions (L*W*H)

(mm)

Package

ADTFv 30-512-7S

30 ~ 512

7.5 Typ.

7.0 Typ.

5.0 Typ.

8bit parallel

13 dBm max.

-40 ~ +85

30*30*12

SMT

ADTFp 30-90-9P

30 ~ 90

9 Typ.

5.6 Typ.

3.5 Typ.

8bit parallel

1 W max.

-40 ~ +85

41*35*17

Pin Type

ADTFp 90-225-9P

90~225

9 Typ.

6.5 Typ.

3.2 Typ.

8bit parallel

1 W max.

-40 ~ +85

58*36*15

Pin Type

ADTFp 225-512-9P

225~512

9 Typ.

7.0 Typ.

3.2 Typ.

8bit parallel

1 W max.

-40 ~ +85

58*36*15

Pin Type

ADTFp 30-90-7D

30~90

7 Typ.

7.0 Typ.

3.5 Typ.

8bit parallel

1 W max.

-40 ~ +85

58*36*15

DipType

ADTFp 90-225-7D

90~225

7.5 Typ.

7.0 Typ.

3.2 Typ.

8bit parallel

1 W max.

-40 ~ +85

58*36*15

DipType

ADTFp 225-512-7D

225~512

7.8 Typ.

7.0 Typ.

4.5 Typ.

8bit parallel

1 W max.

-40 ~ +85

58*36*15

DipType

ADTFcp 225-400-5A

225~400

5.2 Typ.

7.8 Typ.

2.0 Typ.

8bit parallel

1 W max.

-40 ~ +85

63.5*67.9*38.1

SMA

ADTFp 30/520-4S

30 ~ 520

4% Typ.

19 dBc Min.

5.2 Typ.

parallel SPI

1 W max.

-40 ~ +85

44.5*61.0*9.8

SMT

22.0 dBc Typ.

ADTFp 30/520-7S

30 ~ 520

7% Typ.

14 dBc Min.

3.5 Typ.

parallel SPI

1 W max.

-40 ~ +85

44.5*61.0*9.8

SMT

16.0 dBc Typ.

ADTFd 30/520-10S

30 ~ 520

10% Typ.

10.0 dBc Typ.

5.0 Typ.

SPI

1 W max.

-40 ~ +85

30.0*30.0*8.0

SMT

ADTFd 960/1240-6S

960 ~1240

6% Typ.

20.0 dBc Typ.

4.5 Typ.

parallel SPI

1 W max.

-40 ~ +85

38.0*38.0*5.8

SMT
